Core Specifications

• Model No.: 020204F021
• Input: AC90~265Vac, 50/60Hz
• Max Power Consumption: 42W
• Output: 12VDC, Max 3A, Rated Output Power 37.5W
• Power Factor: ＞0.5 @220Vac
• Efficiency: ＞82% @220Vac
• THD: ＜180% @220Vac
• Output Ripple: ≤200mV
• Isolation Type: Input-output isolated
• Withstand Voltage: Input to casing＞1500Vac/2s/0.5mA; Input to output＞500Vac/2s/0.5mA
• Protection Grade: IP66
• Housing: Gray PP plastic (Pantone Cool Gray 10C)
• Wiring: 20AWG high-temperature wire(105℃,600V), fixed length 74±20mm
• Standard Certification: IEC 61347-1:2015+A1:2017 / IEC 61347-2-13:2014+A1:2016
• Warranty: 3 Years

Key Features

1. Full epoxy resin encapsulation on PCB, anti-spark, dustproof and waterproof up to IP66
2. Built-in 20Ω NTC inrush current protection, effectively restrain instant startup surge current
3. Complete safety protection: short-circuit protection (no damage after 20s continuous short), over-voltage protection
4. Universal wide voltage input fits most national power grids worldwide
5. TYCO standard lock-in connectors for stable, quick plug-and-play installation
6. Ultra-long service life up to 50,000 hours, low failure rate only 200PPM
7. Compact standardized plastic casing, convenient for mass installation and replacement

Working Environment

• Operating Temp: 0℃ ~ +50℃
• Storage Temp: -20℃ ~ +60℃

Application Range

Suitable for all kinds of 12VDC LED lighting: LED strips, LED bars, LED panel boards, indoor commercial cabinet lighting, display case lighting and decorative lighting.
