NIRRAU Color LED Short Form Feb2021
Pd
(mW)		 Package Dimmensions
(mm)		 Part Number If
(mA)		 Vf
(V)		 λ
(nm)		 COLOR CRI Φ-Luminous Flux
Φe-Radiant Flux		 Unit  Angle
(°)		 Vrmax
(V)		 Irmax
(uA)		 Ifmax
(mA)		 Ifp(1)
(mA)		 ESD
HBM
(V)
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-620 60 1.8~2.4 615~630 Red * 8.3~13 lm 120 5 10 150 200 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-625 60 1.8~2.4 620~630 Red * 500~800 mcd 120 5 10 150 200 2000
200 2835 2.80 x 3.50 x 0.80 NE-2835-30-625 60 2.2~2.8 618~629 Red * 2100~3000  mcd 120 7 50 60 100 2000
300 2835 2.80 x 3.50 x 0.71 NE-2835-30-625 150 2.2~2.5 620~630 Red * 18~22 lm 120 5 10 150 200 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-583 60 1.8~2.6 580~585 Yellow * 3~6 lm 120 5 10 150 200 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-590 60 1.8~2.6 585~595 Amber * 05~10 lm 120 5 10 150 200 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-593 60 1.8~2.4 590~595 Amber * 500~800 mcd 120 5 10 150 200 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-587 60 1.9~2.5 586~589 Yellow * 500~800 mcd 120 5 10 150 200 2000
200 2835 2.80 x 3.50 x 0.80 NE-2835-20-520 60 3.2~4.0 512~527 Green * 3000~4000  mcd 120 7 50 60 100 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-520 60 2.9~3.5 515~530 Green * 16~22 lm 120 5 10 150 200 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-523 60 2.9~3.5 520~525 Green * 1500~2500 mcd 120 5 10 150 200 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-470 60 2.8~3.5 465~475 Blue * 3~6  lm 120 5 10 150 200 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-465 60 2.8~3.5 460~470 Blue * 500~1000 mcd 120 5 10 150 200 2000
200 2835 2.80 x 3.50 x 0.80 NE-2835-20-455 60 2.9~3.4 450~460 Blue * 550~1000 mcd 120 7 50 60 100 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-453 60 2.8~3.2 450~455 Blue * 2~4  lm 120 5 10 150 200 2000
500 2835 2.80 x 3.50 x 0.80 NE-2835-50-620 150 1.8~2.3 618~627 Red * 3500~4500 mcd 120 7 50 150 350 2000
500 2835 2.80 x 3.50 x 0.80 NE-2835-50-590 150 1.8~2.4 584~594 Yellow * 3500~5500  mcd 120 7 50 150 350 2000
500 2835 2.80 x 3.50 x 0.80 NE-2835-50-520 150 2.8~3.5 515~527 Green * 8200~10500 mcd 120 7 50 150 250 2000
500 2835 2.80 x 3.50 x 0.80 NE-2835-50-455 150 2.9~3.6 450~460 Blue * 1100~1500 mcd 120 7 50 150 300 2000
500 2835 2.80 x 3.50 x 0.70 NE-2835-50-455 150 3.0~3.2 450~460 Blue * 5~10  lm 120 5 10 150 150 2000
500 2835 2.80 x 3.50 x 0.70 NE-2835-50-415 150 3.2~3.6 410~420 Purple * 112~140 mW 120 5 10 150 200 2000
500 2835 2.80 x 3.50 x 0.70 NE-2835-50-405 150 3.2~3.6 400~410 Purple * 112~140 mW 120 5 10 150 180 2000
1000 3030 3.0 x 3.0 X 0.6 NE-3030-A0-520 150 5.8~6.0 520~525 Green * 60~70 lm 120 5 10 150 200 2000
1000 3030 3.0 x 3.0 X 0.6 NE-3030-A0-522 350 3.0~3.2 520~525 Green * 70~90 lm 120 5 10 150 200 2000



NIRRAU White LED Short Form Feb2021
Pd
(mW)		 Package Dimmensions
(mm)		 Part Number If
(mA)		 Vf
(V)		 CCT
(K)  		 COLOR CRI Φ-Luminous Flux
Φe-Radiant Flux		 Unit  Angle
(°)		 Vrmax
(V)		 Irmax
(uA)		 Ifmax
(mA)		 Ifp(1)
(mA)		 ESD
HBM
(V)
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-20 60 2.9~3.4 2000 Warm White > 80 18~22 lm 120 5 10 60 100 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-27 60 2.9~3.4 2700 Warm White > 80 18~24 lm 120 5 10 70 120 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-30 60 2.9~3.4 3000 Warm White > 80 22~26 lm 120 5 10 70 120 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-35 60 2.9~3.4 3500 Warm White > 80 22~28 lm 120 5 10 70 120 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-40 60 2.9~3.4 4000 Natural White > 80 22~28 lm 120 5 10 70 120 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-50 60 2.9~3.4 5000 Natural White > 80 22~28 lm 120 5 10 70 120 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-65 60 2.9~3.4 6500 Cool White > 80 22~28 lm 120 5 10 70 120 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-90 60 2.9~3.4 9000 Ice Blue > 80 22~26 lm 120 5 10 70 120 2000
200 2835 2.80 x 3.50 x 0.70 NE-2835-20-A2 60 2.9~3.4 12000 Ice Blue > 80 20~26 lm 120 5 10 70 120 2000
500 2835 2.80 x 3.50 x 0.70 NE-2835-50-27 150 3.0~3.4 2700 Warm White > 80 45~65 lm 120 7 1 160 300 2000
500 2835 2.80 x 3.50 x 0.70 NE-2835-50-30 150 3.0~3.4 3000 Warm White > 80 55~70 lm 120 5 10 160 300 2000
500 2835 2.80 x 3.50 x 0.70 NE-2835-50-35 150 3.0~3.4 3500 Warm White > 80 55~70 lm 120 5 10 160 300 2000
500 2835 2.80 x 3.50 x 0.70 NE-2835-50-40 150 3.0~3.4 4000 Natural White > 80 55~70 lm 120 5 10 160 300 2000
500 2835 2.80 x 3.50 x 0.70 NE-2835-50-50 150 3.0~3.4 5000 Natural White > 80 55~70 lm 120 5 10 160 300 2000
500 2835 2.80 x 3.50 x 0.70 NE-2835-50-65 150 3.0~3.4 6500 Cool White > 80 55~70 lm 120 5 10 160 300 2000
500 2835 2.80 x 3.50 x 0.65 NE-2835-50-27-9V 60 8.6~9.8 2700 Warm White > 80 55~65 lm 120 15 10 65 120 2000
500 2835 2.80 x 3.50 x 0.65 NE-2835-50-30-9V 60 8.6~9.8 3000 Warm White > 80 60~70 lm 120 15 10 65 120 2000
500 2835 2.80 x 3.50 x 0.65 NE-2835-50-40-9V 60 8.6~9.8 4000 Natural White > 80 65~75 lm 120 15 10 65 120 2000
500 2835 2.80 x 3.50 x 0.65 NE-2835-50-50-9V 60 8.6~9.8 5000 Natural White > 80 65~75 lm 120 15 10 65 120 2000
500 2835 2.80 x 3.50 x 0.65 NE-2835-50-57-9V 60 8.6~9.8 5700 Natural White > 80 65~75 lm 120 15 10 65 120 2000
500 2835 2.80 x 3.50 x 0.65 NE-2835-50-65-9V 60 8.6~9.8 6500 Cool White > 80 65~75 lm 120 15 10 65 120 2000
500 2835 2.80 x 3.50 x 0.70 NE-2835-50-27-18V 30 17.8~19.8 2700 Warm White > 80 65~80 lm 120 30 10 35 100 2000
500 2835 2.80 x 3.50 x 0.70 NE-2835-50-30-18V 30 17.8~19.8 3000 Warm White > 80 65~80 lm 120 30 10 35 100 2000
500 2835 2.80 x 3.50 x 0.70 NE-2835-50-40-18V 30 17.8~19.8 4000 Natural White > 80 75~90 lm 120 30 10 35 100 2000
500 2835 2.80 x 3.50 x 0.70 NE-2835-50-50-18V 30 17.8~19.8 5000 Natural White > 80 60~75 lm 120 30 10 35 100 2000
500 2835 2.80 x 3.50 x 0.70 NE-2835-50-65-18V 30 17.8~19.8 6500 Cool  White > 80 75~90 lm 120 30 10 35 100 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-40 300 2.7~3.0 4000  Natural White >90 24~30 lm 120 5 10 300 400 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-50 300 2.7~3.0 5000  Natural White >90 24~30 lm 120 5 10 300 400 2000
1000 2835 2.80 x 3.50 x 0.60 NE-2835-A0-60 350 2.7~3.0 6000 Cool  White >90 100~160 lm 120 5 10 300 400 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-30-6V 150 5.8~6.6 3000  Warm White >80 105~120 lm 120 10 10 160 200 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-40-6V 150 5.8~6.6 4000  Natural White >80 110~125 lm 120 10 10 160 200 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-57-6V 150 5.8~6.6 5700  Cool White >80 110~125 lm 120 10 10 160 200 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-60-6V 150 5.8~6.6 6000  Cool White >80 100~160 lm 120 5 10 160 200 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-27-9V 100 8.6~9.6 2700 Warm White >80 104~115 lm 120 15 10 110 220 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-30-9V 100 8.6~9.6 3000  Warm White >80 110~125 lm 120 15 10 110 220 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-35-9V 100 8.6~9.6 3500  Warm White >80 110~125 lm 120 15 10 110 220 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-40-9V 100 8.6~9.6 4000  Natural White >80 115~130 lm 120 15 10 110 220 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-50-9V 100 8.6~9.6 5000  Natural White >80 115~130 lm 120 15 10 110 220 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-60-9V 100 8.6~9.6 6000 Cool  White >80 115~130 lm 120 15 10 110 220 2000
1000 2835 2.80 x 3.50 x 0.65 NE-2835-A0-27-36V 30 36~38.4 2700  Warm White > 80 110~130 lm 120 50 10 35 60 2000
1000 2835 2.80 x 3.50 x 0.65 NE-2835-A0-30-36V 30 36~38.4 3000  Warm White > 80 120~140 lm 120 50 10 35 60 2000
1000 2835 2.80 x 3.50 x 0.65 NE-2835-A0-40-36V 30 36~38.4 4000  Natural White > 80 120~150 lm 120 50 10 35 60 2000
1000 2835 2.80 x 3.50 x 0.65 NE-2835-A0-50-36V 30 36~38.4 5000  Natural White > 80 120~150 lm 120 50 10 35 60 2000
1000 2835 2.80 x 3.50 x 0.65 NE-2835-A0-57-36V 30 36~38.4 5700 Cool White > 80 120~150 lm 120 50 10 35 60 2000
1000 2835 2.80 x 3.50 x 0.65 NE-2835-A0-65-36V 30 36~38.4 6500  Cool White > 80 120~150 lm 120 50 10 35 60 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-27-54V 20 52.4~55.6 2700  Warm White > 80 110~130 lm 120 50 10 20 25 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-30-54V 20 52.4~55.6 3000  Warm White > 80 120~140 lm 120 50 10 20 25 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-40-54V 20 52.4~55.6 4000  Natural White > 80 120~150 lm 120 50 10 20 25 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-50-54V 20 52.4~55.6 5000  Natural White > 80 120~150 lm 120 50 10 20 25 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-57-54V 20 52.4~55.6 5700  Cool White > 80 120~150 lm 120 50 10 20 25 2000
1000 2835 2.80 x 3.50 x 0.70 NE-2835-A0-65-54V 20 52.4~55.6 6500  Cool White > 80 120~150 lm 120 50 10 20 25 2000
100 3528 3.50 x 2.80 x 1.05 NE-3528-10-28 30 2.7~3.5 2800 Warm White > 80 9~14 lm 120 5 10 40 100 2000
100 3528 3.50 x 2.80 x 1.05 NE-3528-10-30 30 2.7~3.5 3000 Warm White > 80 8~13 lm 120 5 10 40 100 2000
100 3528 3.50 x 2.80 x 1.05 NE-3528-10-35 30 2.7~3.5 3500 Warm White > 80 9~14 lm 120 5 10 40 100 2000
100 3528 3.50 x 2.80 x 1.05 NE-3528-10-40 30 2.7~3.5 4000 Natural White > 80 10~15 lm 120 5 10 40 100 2000
100 3528 3.50 x 2.80 x 1.80 NE-3528-10-43 30 2.7~3.4 4300 Natural White >80 3500~5300 mcd 120 5 10 40 100 2000
100 3528 3.50 x 2.80 x 1.90 NE-3528-10-50 30 2.9~3.5 5000 Natural White >70 3500~4750 mcd 120 5 10 40 100 2000
100 3528 3.50 x 2.80 x 1.80 NE-3528-10-55 30 2.8~3.5 5500 CoolWhite >70 9~14 lm 120 5 10 40 100 2000
100 3528 3.50 x 2.80 x 1.05 NE-3528-10-58 30 2.7~3.5 5800 CoolWhite >70 10~15 lm 120 5 10 40 100 2000
100 3528 3.50 x 2.80 x 1.05 NE-3528-10-60 30 2.7~3.5 6000 CoolWhite >70 9~14 lm 120 5 10 40 100 2000
100 3528 3.50 x 2.80 x 1.80 NE-3528-10-65 30 2.8~3.5 6500 CoolWhite >70 9~14 lm 120 5 10 40 100 2000
100 3528 3.50 x 2.80 x 1.80 NE-3528-10-68 30 2.8~3.5 6800 CoolWhite >70 9~14 lm 120 5 10 40 100 2000
1000 3030 3.0 x 3.0 X 0.6 NE-3030-A0-60 350 2.8~3.6 6000 CoolWhite >70 100~160 lm 120 5 10 350 400 2000
1000 3030 3.0 x 3.0 X 0.6 NE-3030-A0-60 150 5.8~6.8 6000 CoolWhite >70 100~160 lm 120 10 10 150 200 2000
1000 3030 3.0 x 3.0 X 0.7 NE-3030-A0-43 150 6.0~6.6 4300 Natural White >80 130~145 lm 120 10 10 150 180 2000
200 5050 5.0 x 5.0 x 1.6 NE-5050-20-24 60 2.8~3.4 2400 Warm White >80 4300~8000  mcd 120 10 5 65 100 2000
200 5050 5.0 x 5.0 x 1.6 NE-5050-20-27 60 2.8~3.4 2700 Warm White >80  5300~10000  mcd 120 10 5 65 100 2000
200 5050 5.0 x 5.0 x 1.6 NE-5050-20-30 60 2.8~3.4 3000 Warm White >80  5300~10000 mcd 120 10 5 65 100 2000
200 5050 5.0 x 5.0 x 1.6 NE-5050-20-40 60 2.8~3.4 4000 Natural White >80  5300~10000  mcd 120 10 5 65 100 2000
200 5050 5.0 x 5.0 x 1.6 NE-5050-20-45 60 2.8~3.4 4500 Natural White >80  5300~10000  mcd 120 10 5 65 100 2000
200 5050 5.0 x 5.0 x 1.6 NE-5050-20-65 60 2.8~3.4 6500 Cool White >80  5300~10000  mcd 120 10 5 65 100 2000
200 5050 5.0 × 5.0 × 1.6 NE-5050-20-27 60 2.8~3.6 2700 Warm White >80 20~26 lm 120 7 50 75 300 2000
200 5050 5.0 × 5.0 × 1.6 NE-5050-20-30 60 2.8~3.6 3000 Warm White >80 20~26 lm 120 7 50 75 300 2000
200 5050 5.0 × 5.0 × 1.6 NE-5050-20-35 60 2.8~3.6 3500 Warm White >80 20~26 lm 120 7 50 75 300 2000
200 5050 5.0 × 5.0 × 1.6 NE-5050-20-40 60 2.8~3.6 4000 Natural White >80 20~26 lm 120 7 50 75 300 2000
200 5050 5.0 × 5.0 × 1.6 NE-5050-20-50 60 2.8~3.6 5000 Natural White >80 24~28 lm 120 7 50 75 300 2000
200 5050 5.0 × 5.0 × 1.6 NE-5050-20-60 60 2.8~3.6 6000 Cool  White >80 24~28 lm 120 7 50 75 300 2000
Product Specification

Note 1: Using 1/10 duty cycle, pulse width 10ms.
Note 2: A first approximation, only for give a idea of value, is use 5000mcd ≈ 12lm, because there are many relevant factors to be taken in account, in this kind of measure.
Note 3: Due to constant pursuit of refinement these specifications can be modified at any time without notice.
Note 4: If you need a specific LED, not found in this list, feel free contact us via info@nirrau.com.cn, we have new items being added almost weekly.
Note 5: If you have any doubt, comment, suggestion about this short form or need more information, contact us via info@nirrau.com.cn, we are pleased support you.

Simbol Description
Angle Viewing Angle
CCT Correlated color temperature
CRI Color Rendering Index
ESD Eletrostatic discharge
HBM Human body model
If Forward current
Ifmax Maximum forward current
Ifp Peak forward current
Irmax Maximum reverse current
Pd Power dissipation
Vf Forward voltage
Vrmax Maximum reverse voltage
Φ Luminous flux [lm] and [mcd]
Φe Radiant flux [mW]
λ                      Dominant Wavelength
